RASTERS CABINETS
$0
SOLD OUT
RASTERS Cabinets are modular storage units based on a grid system commonly used by architects and engineers to organise space. The framework is formed by solid steamed beech slats, forming a continuous wooden lattice. MDF shelves veneered in steamed beech are set within this structure, while powder-coated steel doors, drawers and back panels introduce colour into the grid, creating strong visual anchors. Available in four heights, the system allows flexible compositions and continuous horizontal expansion. Black polyamide connectors enable precise reconfiguration as spatial needs evolve.
Dimensions and technical drawing
EXAMPLE 1
1u. - Base module S
1u. - Extra module S
1u. - Drop down door + backboard
EXAMPLE 2
1u. - Base module S
2u. - Extra module S
2u. - Drawer + backpanel
EXAMPLE 3
1u. - Base module M
1u. - Extra module M
1u. - Cross brace M
2u. - Shelves
EXAMPLE 4
1u. - Base module M
2u. - Extra module M
1u. - Cross brace M
3u. - Shelves
EXAMPLE 5
1u. - Base module L
2u. - Extra module L
6u. - Shelves
1u. - Doors L + backpanel
1u. - Drawer + backpanel
1u. - Drop down door + backpanel
EXAMPLE 6
1 u. - Base module XL
2u. - Extra module XL
8u. - Shelves
1u. - Doors XL + backpanel
Materials and finishes
Rasters Cabinets is a modular cabinet system composed of open structural modules designed to be combined laterally, using eccentric fittings and custom-made nylon components, allowing configurations of up to four modules in different heights. When creating a cabinet, modules of different heights can be combined within the same composition.
The base module consists of an open box construction, without front or back enclosure in steamed beech wood. Side panels are made of lattice structures composed of solid beech slats, 7 mm thick, with square free openings of 23 × 23 mm. Top and bottom panels are made of 30 mm MDF veneered in steamed beech. All is water-based matte varnish finished.
The system does not include a back panel by default. Structural stability is ensured by accessories with back panels or by rear cross braces, which are mandatory every two modules when no back accessories are used.Steel feet with integrated levelling glides are included. Feet are powder-coated in matte black (RAL 9005).
Downloads
Dimensions and technical drawing
EXAMPLE 1
1u. - Base module S
1u. - Extra module S
1u. - Drop down door + backboard
EXAMPLE 2
1u. - Base module S
2u. - Extra module S
2u. - Drawer + backpanel
EXAMPLE 3
1u. - Base module M
1u. - Extra module M
1u. - Cross brace M
2u. - Shelves
EXAMPLE 4
1u. - Base module M
2u. - Extra module M
1u. - Cross brace M
3u. - Shelves
EXAMPLE 5
1u. - Base module L
2u. - Extra module L
6u. - Shelves
1u. - Doors L + backpanel
1u. - Drawer + backpanel
1u. - Drop down door + backpanel
EXAMPLE 6
1 u. - Base module XL
2u. - Extra module XL
8u. - Shelves
1u. - Doors XL + backpanel
Materials and finishes
Rasters Cabinets is a modular cabinet system composed of open structural modules designed to be combined laterally, using eccentric fittings and custom-made nylon components, allowing configurations of up to four modules in different heights. When creating a cabinet, modules of different heights can be combined within the same composition.
The base module consists of an open box construction, without front or back enclosure in steamed beech wood. Side panels are made of lattice structures composed of solid beech slats, 7 mm thick, with square free openings of 23 × 23 mm. Top and bottom panels are made of 30 mm MDF veneered in steamed beech. All is water-based matte varnish finished.
The system does not include a back panel by default. Structural stability is ensured by accessories with back panels or by rear cross braces, which are mandatory every two modules when no back accessories are used.Steel feet with integrated levelling glides are included. Feet are powder-coated in matte black (RAL 9005).
Downloads
ACCESSORIES FINISHES
Green RAL 6016
Light blue RAL 5024
Light grey RAL 7044
Off-white RAL 9001
Red RAL 3000
